HIKMicro Lynx LC06

Specification

Thermal Module

Image Sensor VOx Uncooled Focal Plane Arrays
Resolution 160 × 120
Frame Frequency 50 Hz
Pixel Interval 17 μm
Response Waveband 8 μm to 14 μm
NETD Less than 35 mK (@25°C),F#=1.1
Focal Length 6.2 mm
IFOV 2.74 mrad
Field of View 24.7° × 18.7° (H × V)
Aperture F1.1
Image Display
Monitor 0.2 inch, LCOS, 720 × 540
Palettes Black Hot, White Hot, Red Hot, Fusion
FFC (Flat Field Correction) Mode Auto, Manual, External Correction
Digital Zoom 1 ×, 2 ×, 4 ×
Smart Function
Hot Track Yes
Detection Range 219 m

System

Storage Built-in memory module (8 GB)
Record Video Yes
Capture Snapshot Yes
Wi-Fi Yes
Standby Mode Yes

Power Supply

Battery Type Rechargeable Lithium Battery
Battery Operating Time 10 hours continuous running with CVBS and Wi-Fi hot spot off (@25°C)
7.5 hours continuous running with CVBS and Wi-Fi hot spot on (@25°C)
Battery Capacity Display Yes

General

Power 5 VDC/2 A, 1.5 W, Type-C Interface
Work Temperature/Humidity From -20 °C to 55 °C (-4 °F to 131 °F); Humidity: 90% or Less
Protection Level IP67
Dimension 158.3 mm × 61 mm × 57 mm (6.23" × 2.40" × 2.24")
Weight 250 g (0.55 lb)
